19 Using the device overview 3 Starting point of the functions The 'Station Info' provides access to the following functions: View status of inputs and outputs View and change tag values Set date and time of LOGO! Access to the Web server Operating Manual, 04/2016, A5E AA 19 20 Using the device overview 3.1 Displaying the IO status of inputs/outputs, bit memories and keys 3.1 Displaying the IO status of inputs/outputs, bit memories and keys Output of the I/O status Under 'IO State Selection', you access the status displays of the inputs and outputs, bit memories, LOGO!

Keys and text display. 20 Operating Manual, 04/2016, A5E AA. 21 Using the device overview 3.1 Displaying the IO status of inputs/outputs, bit memories and keys Operating Manual, 04/2016, A5E AA 21 22 Using the device overview 3.1 Displaying the IO status of inputs/outputs, bit memories and keys Example: Output of inputs Click Inputs in the 'IO State Selection'. The output of the inputs is started automatically in the app.

You can view newer or older process values by swiping down and up. You can show the other inputs by swiping left.

The set update rate determines how frequently the inputs are written. See also:refresh frequency (Page 39) 22 Operating Manual, 04/2016, A5E AA. 23 Using the device overview 3.1 Displaying the IO status of inputs/outputs, bit memories and keys Operating Manual, 04/2016, A5E AA 23 24 Using the device overview 3.2 Displaying and changing tags in the controller 3.2 Displaying and changing tags in the controller Digital and analog network inputs You can address digital and analog network inputs directly with the respective V address in the LOGO! Analog FB parameters To display or change analog FB parameters in the LOGO! App, you must enter these FB parameters in the parameter VM table in LOGO!

Soft Comfort (menu item 'Tools > Parameter VM Mapping') FB Parameters - Read only (actual value in LOGO!) FB Parameters - Read and write 24 Operating Manual, 04/2016, A5E AA 25 Using the device overview 3.2 Displaying and changing tags in the controller Calling tags in the LOGO! In the 'Station Info' mask, select 'Tags' and click the plus symbol. The 'Add Tag' dialog opens. Enter the following data: Address: The address corresponds to the V address of your network input or FB parameter in the LOGO! Name: Enter any name for the tag. The name is used only for display in the app. Format: Under Format, select the display format of the tag.

For digital tags, select 'BINARY'; for analog tags, select the required display format, e.g. Click on the floppy disk icon to save the tag. The tag is displayed in the tag list. In the tag list, you can create a maximum of 20 tags for one LOGO!

Operating Manual, 04/2016, A5E AA 25 26 Using the device overview 3.3 Outputting the IO status and tag status via the trend view Changing the tag value 1. In the tag list, click on the tag with the value you want to change. The 'Change value on PLC' dialog opens. Enter the desired value under 'New Value'. When you tap the 'Write to LOGO!' Button, the value from LOGO! Is applied as the current tag value.
