RISCV_Piccolo_v1 Implementation of RISC-V RV32IM. Simple in-order 3-stage pipeline. Low resources (e.g., FPGA softcore).

MIT License (see LICENSE.txt) Introduction This is a preliminary release of Bluespec Inc.' S Piccolo, which is a an implementation of the RISC-V Instruction Set Architecture (ISA).

• RV32IM variant of the RISC-V ISA. Crashday isohunt. • Simple 3-stage in-order pipeline, target for low-resource applications, such as FPGA softcores. • User- and Machine-mode privilege levels. • No memory management, no floating point. This repository contains all the Verilog source files for the Piccolo CPU, as well as for surrounding modules that enable system-level execution ( Top_Sim_Standalone, SoC_Top, Sim_Driver, ICache, DCache, Fabric, Mem_Controller, Mem_Model, UART). In addition, this repository contains two pre-built simulation executables that you can run immediately (on 64-bit Linux platforms) built from the same source code. One uses Bluespec's Bluesim simulator, and the other uses the Verilator open source Verilog simulator.

Finally, this repository contains some pre-compiled RISC-V ELF binaries for C and RISC-V assembly language programs, compiled using the RISC-V gcc toolchain. You can run the simulators on these ELF files, i.e., you will be simulating a CPU-Caches-Fabric-Memory-UART 'SoC' system, where the CPU is the Piccolo RISC-V CPU, and it is executing one of the ELF binaries. If you have the RISC-V gcc toolchain (from riscv.org) you should be able to compile other programs into ELF executables and run them on these simulators. The Makefiles in the Bluesim/ and Verilogsim directories provide examples of how to invoke the simulator on an executable. NOTE: these simulators have been compiled to run on 64-bit x86 Linux platforms only (such as Ubuntu and Debian).

We have no plan to produce versions for other platforms (e.g., Windows, Mac OS). Repository contents: • Bluesim/ Contains a pre-built Linux executable using Bluespec, Inc.' S Bluesim simulator.

The Makefile allows running the simulator on any of the pre-compiled ELF files in Programs/ directory. For example, $ make do_test_hello runs the 'Hello World!' • Verilogsim/ Contains a pre-built Linux executable that is a Verilog simulator built using Verilator. The Makefile allows running the simulator on any of the pre-compiled ELF files in Programs/ directory. For example, $ make do_test_hello runs the 'Hello World!' • verilog/ Verilog RTL from which the Verilog simulation executable was built.

This Verilog RTL is not hand-written, but generated from Bluespec BSV sources (not included) by Bluespec's bsc compiler. It's moderately readable (YMMV).

• Cpp_src/ Contains the Verilator top-level driver sim_main.cpp and a few other C++ files that are imported by the Verilog code. • Makefile_verilator Makefile to rebuild the Verilog simulation executable using Verilator (see below).

This will allow you to tell Verilator to incorporate VCD dumping, profiling, etc. • RISCV_Programs/ • C_tests_RV32IM/ • asm_tests_RV32IM/ These contain a number of sub-directories (e.g., 'hello/', containing a 'Hello World!' Each directory contains a.c (C) or.S (assembly) source file, a pre-compiled RISC-V RV32IM ELF executable, and a.text dis-assembly of the ELF file. Running the Bluesim simulator on RISV-V ELF files You should be in the Bluesim directory: $ cd Bluesim To run an individual program, e.g., 'Hello World!' : $ make do_test_hello To run all programs (file sample_transcript is a transcript of this): $ make do_tests If you set the environment variable SIM_VERBOSITY (to 1, 2.) it will produce increasingly detailed simulation traces indicating activity on a clock-by-clock basis in the CPU pipeline, caches, interconnect fabric and memory controller. Note: The make commands invoke the Bluesim executable: $ top_Sim_Standalone_exe If you provide the flag -V it will dump VCDs waveforms to the file dump.vcd.
